KF Vacuum Chain Clamp KF16-KF63 with Hand Knob SS304
Item specifics
- Product Name
- KF Vacuum chain clamp KF16-KF63
- Size
- KF10,KF25,KF40,KF50,KF63
- Seal material
- Viton,Silicone,Buna-N seal
- Helium Leak Test
- 1×10 -9 Pa・m³/sec or less
Review
Description
KF Vacuum Chain Clamp KF16-KF63 with hand Knob SS304 feature
advantage
●Used in high-tech industries such as semiconductor manufacturing,national defense research,aerospace,bio pharmaceutical,LCD,etc
●Before shipment, vacuum clamps need to undergo clamp testing, including but not limited to elastic clamps, fire clamps, water pipe clamps, etc., to ensure that their quality and performance meet standards.
●The packaging method of vacuum clamps varies depending on their material. Stainless steel vacuum clamps are packaged and sold after secondary polishing treatment, while aluminum alloy vacuum clamps are cleaned and packaged after electrolytic polishing.

KF Vacuum Chain Clamp KF16-KF63 with hand knob SS304 specifications
Product Name | KF Vacuum flange chain clamp KF16-KF63 |
Brand | RUIJIA |
Size | KF10,KF25,KF40,KF50,KF63 |
Material | SS304, SS316L, 6061T6 Alu, EN1.4301, EN1.4404 |
Seal material | Viton,Silicone,Buna-N seal |
Standard | KF Standard |
Temperature | -200~800℃ |
Working Pressure | Vacuum~atmosphere pressure |
Helium Leak Test | 1×10 -9 Pa・m³/sec or less |
Packing | sealed plastic bag with a protective plastic cap. |
KF Vacuum clamp types | KF bulkhead clamp,KF spring clamp with plastic nut,KF spring clamp with wing nut,KF toggle clamp with lock,KF chain clamp(KF16-63),KF chain clamp(KF80-200) |
KF Vacuum Chain Clamp KF16-KF63 with hand knob SS304 parameters

KF Vacuum flange chain clamp KF16-KF63 Unit:mm
Model No. | Flange size | Material | A | B | T |
CC-K-16 | KF10/16 | Block Aluminum | 22 | 56 | 20.3 |
CC-K-25 | KF25 | Block Aluminum | 32 | 66 | 20.3 |
CC-K-40 | KF40 | Block Aluminum | 46 | 80 | 20.3 |
CC-K-50 | KF50 | Block Aluminum | 69 | 100 | 20.3 |
CC-K-63 | KF63 | Block Aluminum | 78 | 112 | 20.3 |
KF Vacuum Chain Clamp KF16-KF63 with hand knob SS304 detail

Production Center


Packing & Shipping


Application
