CF Vacuum 2 Way Ball Valves Stainless Steel 304 for Vacuum System Wholesales
Item specifics
- Size
- CF16,CF25,CF40,CF50,CF63,CF80,CF100.
- Material
- SS304, SS316L
- Seal material
- Viton,Silicone,Buna-N seal
- Standard
- CF Standard
- Temperature
- -200~800℃
- Working Pressure
- Vacuum~atmosphere pressure
Review
Description
CF Vacuum 2 Way Ball Valves Stainless Steel 304 for Vacuum System Wholesales Feature
●Application: Vacuum ball valves are used to control the flow of media, ensuring the vacuum degree and work efficiency of the system.
●Size:the size and specifications of ball valves include nominal diameter (DN), external dimensions, flange standards, gas source pressure, applicable range, leakage rate, etc.
●Testing:Sealing performance testing, pressure resistance testing, and material compatibility testing are conducted to ensure the reliability and safety of valves under extreme conditions
CF Vacuum 2 Way Ball Valves Stainless Steel 304 for Vacuum System Wholesales Specifications
|
Product Name
|
CF Vacuum 2 Way Ball Valves Stainless Steel 304 for Vacuum System Wholesales |
||
Brand | RUIJIA | ||
Size | CF16,CF25,CF40,CF50,CF63,CF80,CF100. | ||
Material | SS304, SS316L | ||
Seal material | Viton,Silicone,Buna-N seal | ||
Standard | CF Standard | ||
Temperature | -200~800°C | ||
Working Pressure | Vacuum~atmosphere pressure | ||
|
Helium Leak Test
|
1×10 -9 Pa・m³/sec or less
|
||
|
Packing
|
sealed plastic bag with a protective plastic cap.
|
||
|
Vacuum Valve types
|
Vacuum ball valve,Vacuum Electric ball valve,Vacuum Pneumatic Actuated ball Valve, Vacuum butterfly valve manual/pneumatic/Electric,Vacuum Angle Valve,
Vacuum Manual /Pneumatic /Electric Neutral Plate Valve |
||
Product parameters
CF Vacuum 2 Way Ball Valves Stainless Steel 304 for Vacuum System Wholesales Unit:mm
| Flange Size | Material | Tube Size | A/inch | B/inch |
| CF16 | SS304 | 3/4'' | 1.77'' | 4.69'' |
| CF25 | SS304 | 1'' | 2.09'' | 4.88'' |
| CF40 | SS304 | 1 1/2'' | 2.72'' | 5.63'' |
| CF50 | SS304 | 2'' | 3.07'' | 6.38'' |
| CF63 | SS304 | 2 1/2'' | 3.86'' | 7.76'' |
| CF80 | SS304 | 3'' | 4.17'' | 9.02'' |
| CF100 | SS304 | 4'' | 5.31'' | 9.57'' |
Special Sizes Available Upon Request.
