KF High Vacuum Ball Valves,3-Way Manual Ball valves for Vacuum System Wholesale China
Item specifics
- Size
- KF25,KF40,KF50.
- Material
- SS304, SS316L
- Seal material
- Viton,Silicone,Buna-N seal
- Temperature
- -200~800℃
- Helium Leak Test
- 1×10 -9 Pa・m³/sec or less
- Packing
- sealed plastic bag with a protective plastic cap.
Review
Description
KF High Vacuum Ball Valves,3-Way Manual Ball valves for Vacuum System Wholesale China Feature
●Application:Used in situations where it is necessary to change the flow direction of the medium or cut off the flow of the medium, such as petroleum, chemical, natural gas, power plants, metallurgy, national defense research and other fields
●Size:Depending on specific application requirements and design specifications
●Finish:Polished surface or sand blasting surface.
KF High Vacuum Ball Valves,3-Way Manual Ball valves for Vacuum System Wholesale China Specifications
|
Product Name
|
KF High Vacuum Ball Valves,3-Way Manual Ball valves for Vacuum System Wholesale China
|
||
Brand | RUIJIA | ||
Size | KF25,KF40,KF50 | ||
Material | SS304, SS316L | ||
Seal material | Viton,Silicone,Buna-N seal | ||
Standard | KF Standard | ||
Temperature | -200~800 | ||
Working Pressure | Vacuum~atmosphere pressure | ||
|
Helium Leak Test
|
1×10 -9 Pa・m³/sec or less
|
||
|
Packing
|
sealed plastic bag with a protective plastic cap.
|
||
|
Vacuum Valve types
|
Vacuum ball valve,Vacuum Electric ball valve,Vacuum Pneumatic Actuated ball Valve, Vacuum butterfly valve manual/pneumatic/Electric,Vacuum Angle Valve,Vacuum Manual /Pneumatic /Electric Neutral Plate Valve
|
||
Product parameters
KF High Vacuum Ball Valves,3-Way Manual Ball valves for Vacuum System Wholesale China Unit:mm
| Size | Material | A/mm | B/mm | C/mm |
| KF25 (1'') | SS304 | 110 | 50 | 55 |
| KF40 (1 1/2"') | SS304 | 160 | 68 | 80 |
| KF50 (2'') | SS304 | 180 | 73 | 90 |
Special Sizes Available Upon Request.
Production Center
Application
