Item specifics

Size
KF16,KF25,KF40,KF50
Material
SS304, SS316L
Seal material
Viton,Silicone,Buna-N seal
Temperature
-200~800℃
Helium Leak Test
1×10 -9 Pa・m³/sec or less

Review

Description

KF Six-Way Crosses Vacuum Stainless Steel Flange Component & Fittings Wholesale China feature
●Application field: Mainly used to prevent impurities from adhering to pipes in a molten state, achieving pipe sizing and cooling through vacuum holes on vacuum pipelines.
● Testing: the six way crosses correctly switch the fluid flow direction; Performance testing checks whether the performance indicators of the components meet the specified requirements, such as the sizing accuracy and cooling efficiency of the vacuum pipe sizing device
● Surface finish: Some applications require a high level of cleanliness, so choose fittings with appropriate surface finishes to minimize particle generation.


KF vacuum fittings 6 way crosses
KF Six-Way Crosses Vacuum Stainless Steel Flange Component & Fittings Wholesale China specifications
Product Name
KF Six-Way Crosses Vacuum Stainless Steel Flange Component & Fittings Wholesale China
Brand
RUIJIA
Size
KF16,KF25,KF40,KF50
Material
SS304, SS316L
Seal material
Viton,Silicone,Buna-N seal
Standard
KF Standard
Temperature
-200~800
Working Pressure
Vacuum~atmosphere pressure
Helium Leak Test
1×10 -9 Pa・m³/sec or less
Packing
sealed plastic bag with a protective plastic cap.
KF flange fittings types
KF 90 degree elbow, KF 90 degree elbow aluminium, KF Tees,KF Tee aluminium,KF unequal Tees, KF 4-way crosses,KF Five-way crosses, KF six-way crosses.
Product parameters
KF Six-Way Crosses Vacuum Stainless Steel Flange Component & Fittings Wholesale China                                         Unit:mm
Model No. Material A B C D
KF16SXA 304S.S 38.3 19.05 30 76.6
KF25SXA 304S.S 51.4 25.4 40 102.8
KF40SXA 304S.S 61 38.1 55 122
KF50SXA 304S.S 80 50.8 75 160
Special Sizes Available Upon Request.
