Item specifics

Size
CF16,CF35,CF63,CF100,CF150
Material
SS304, SS316L
Seal material
Oxygen free copper, silver plated copper
Temperature
-200~800℃
Helium Leak Test
1×10 -9 Pa・m³/sec or less
Packing
sealed plastic bag with a protective plastic cap.

Review

Description

CF Vacuum Flange Fittings 4 way Crosses-Two Flange Rotatable Wholesale China feature
●Mainly used in ultra-high vacuum systems. The connection method of 4 way crosses is suitable for applications that require high temperature baking. Its nominal diameter sizes include CF16, CF35, CF63, CF100, CF150 and the applicable vacuum degree is up to 10 ^ -12 mbar.
●Packaging method: Special packaging materials are usually used for protection. During packaging, anti-static materials and foam packaging will be used to reduce the damage to products caused by vibration and collision during transportation
●Testing:Appearance inspection, size inspection, sealing performance testing


CF Vacuum Flange fittings 4 way Crosses
CF Vacuum Flange Fittings 4 way Crosses-Two Flange Rotatable Wholesale China specifications
Product Name
CF Vacuum Flange Fittings 4 way Crosses-Two Flange Rotatable Wholesale China
Brand
RUIJIA
Size
CF16,CF35,CF63,CF100,CF150
Material
SS304, SS316L
Seal material
Oxygen free copper, silver plated copper
Standard
CF Standard
Temperature
-200~800
Working Pressure
Vacuum~atmosphere pressure
Helium Leak Test
1×10 -9 Pa・m³/sec or less
Packing
sealed plastic bag with a protective plastic cap.
CF flange fittings types
CF 90 degree Elbow fixed,CF 90 degree Elbow Rotatable,CF Tees fixed,CF Tees-Two Flange Rotatable,CF 4 way crosses fixed,CF Five way Crosses Fixed, CF six way crosses fixed,CF Cubes with Fractional thread.
Product parameters
CF Vacuum Flange Fittings 4 way Crosses-Two Flange Rotatable Wholesale China                                                                   Unit:mm
Model No. Material A B C D
CF16X 304S.S 47.2 19.05 33.8 94.4
CF35X 304S.S 62.5 38.1 69.5 125
CF63X 304S.S 85.7 63.5 113.6 171.4
CF100X 304S.S 109.5 101.6 151.6 219
CF150X 304S.S 139.7 152.4 202.5 279.4
Special Size available Upon Request.
Part number plus "k" for sand blasting surface.
Part number Plus "L" for polished surface.
