KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China

Item specifics

Size
KF16-KF50
Material
SS304, SS316L
Seal material
Viton,Silicone,Buna-N seal
Standard
KF Standard
Temperature
-200~800℃
Helium Leak Test
1×10 -9 Pa・m³/sec or less

Review

Description

KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China  feature
● Mainly used in high-tech industries such as semiconductor manufacturing, defense research, aerospace, biopharmaceuticals, LCD displays, photovoltaics, and solar energy. and KF vacuum interfaces have become an important choice in these fields due to their precise size, simple structure, and compact advantages.
●Before delivery, the packaging of KF vacuum connector usually includes the use of appropriate packaging materials, such as shockproof foam, plastic bags or cartons, to ensure that the connector will not be damaged during transportation.
●When assembled and used, KF vacuum joints are usually combined with vacuum clamp heads, center brackets, vacuum blind plates, and other accessories. They can also be used in conjunction with vacuum valves, vacuum tees, vacuum elbows, etc.


KF half nipple
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China  specifications
Product Name
KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China
Brand
RUIJIA
Size
KF16-KF50
Material
SS304, SS316L
Seal material
Viton,Silicone,Buna-N seal
Standard
KF Standard
Temperature
-200~800
Working Pressure
Vacuum~atmosphere pressure
Helium Leak Test
1×10 -9 Pa・m³/sec or less
Packing
sealed plastic bag with a protective plastic cap.
Surface
Sand Blasting or Polished Surface
Product parameters

KF Half Nipple for long Vacuum flanges Fittings KF16-KF50 Wholesale China                                                          Unit:mm
Model No. Material A B C Available Area
KF10LHNSA S.S.304 30 12.7 40 U.S.A
KF16LHNSA S.S.304 30 19.05 40 U.S.A
KF25LHNSA S.S.304 40 25.4 40 U.S.A
KF40LHNSA S.S.304 55 38.1 40 U.S.A
KF50LHNSA S.S.304 75 50.8 40 U.S.A
KF10LHNAA S.S.304 30 12.7 40 U.S.A
KF16LHNAA S.S.304 30 19.05 40 U.S.A
KF25LHNAA S.S.304 40 25.4 40 U.S.A
KF40LHNAA S.S.304 55 38.1 40 U.S.A
KF50LHNAA S.S.304 75 50.8 40 U.S.A
KF10LHNSE S.S.304 30 14 70 Europe
KF16LHNSE S.S.304 30 20 70 Europe
KF25LHNSE S.S.304 40 28 70 Europe
KF40LHNSE S.S.304 55 45 70 Europe
KF50LHNSE S.S.304 75 57 70 Europe
KF50LHNSJ S.S.304 75 60.5 40 Japan
Special Sizes Available Upon Request.
Production Center
Application
Applications for this system are as varied as the imagination can make them.
Some examples are:
*Roughing and foreline plumbing for large vacuum system.
*High vacuum, high conductance, inter-connections.
*Modular system which will be modified frequently.
*System requiring frequent cleaning.
*Experimental system in research laboratories.
