ISO Vacuum Flange Fittings 45 Degree Elbow
Item specifics
- Product Name
- ISO Vacuum flange fittings 45 degree elbow
- Size
- ISO63,ISO80,ISO100
- Seal material
- Viton,Silicone,Buna-N seal
- Material
- SS304, SS316L
Review
Description
ISO Vacuum Flange Fittings 45 Degree Elbow feature
advantage
●Application ：application areas include but are not limited to scientific research, semiconductor manufacturing, and other industrial fields that require high purity and high vacuum.
● Packaging methods: including bubble wrap packaging, anti-static packaging bags, and customized wooden or metal protective boxes.
●Testing：the testing items for vacuum pipe fittings include appearance quality testing, dimensional accuracy testing, material performance testing, pressure testing, sealing testing, and corrosion resistance testing.
ISO Vacuum Flange Fittings 45 Degree Elbow specifications
| Product Name | ISO Vacuum flange fittings 45 degree elbow |
| Brand | RUIJIA |
| Size | ISO63,ISO80,ISO100 |
| Material | SS304, SS316L |
| Seal material | Viton,Silicone,Buna-N seal |
| Standard | ISO Standard |
| Temperature | -200~800℃ |
| Working Pressure | Vacuum~atmosphere pressure |
| Helium Leak Test | 1×10 -9 Pa・m³/sec or less |
| Packing | sealed plastic bag with a protective plastic cap. |
| ISO flange fittings types | ISO 90 degree elbow,ISO Tees, ISO 4-way crosses,ISO five-way crosses, ISO six-way crosses. |
ISO Vacuum Flange Fittings 45 Degree Elbow parameters
ISO Vacuum flange fittings 45 degree elbow Unit:mm
| Model No. | Material | A | B | C | D |
| ISO63XA | 304S.S | 82.8 | 63.5 | 95 | 165.6 |
| ISO80XA | 304S.S | 89.15 | 76.2 | 110 | 178.3 |
| ISO100XA | 304S.S | 105 | 101.6 | 130 | 210 |
| ISO160XA | 304S.S | 133.6 | 152.4 | 180 | 267.2 |
Special Size available Upon Request.
Part number plus "k" for sand blasting surface.
Part number Plus "L" for polished surface.
