High Purity Tubings Stainless steel ASTM A270 tubings
Item specifics
- Product Name
- High Purity Tubing ASTM A270
- Size
- 6.35mm-152.4mm
- Material
- SS304, SS316L
- Thickness
- 0.89mm-2.77mm
- Lenght
- 4M,6M,or Customized
Review
Description
High Purity Tubings ASTM A270
●Widely used in precision instruments, medical, semiconductors and electronic tubes, heat exchange equipment, automobile pipelines, laboratory gas lines, and aerospace fields.
●The packaging before shipment usually Each tube will be packed in a plastic bag, then several tubes will be packed in hollow plate or weaving bags.
●We can provide AP Grade,BA Grade,MP Grade and EP Grade Hygienic stainless steel tubes.
High Purity Tubings ASTM A270
|
Product Name
|
High Purity Tubing ASTM A270 |
||
Brand | RUIJIA | ||
Size | 6.35mm-152.4mm | ||
Material | SS304, SS316L | ||
Thickness | 0.89mm-2.77mm | ||
Length | 4M,6M,or Customized | ||
Packing | Each tube will be packed in a plastic bag, then several tubes will be packed in hollow plate or weaving bags. | ||
Surface | Mill Finish, Mirror Finish, Satin Finish | ||
Product parameters
High Purity Tubing ASTM A270 Unit:mm
| Tube OD(inches) | Thickness(inches) | Tube OD(mm) | Thickness(mm) | Weight(kg/m) |
| 1/4″ | 0.035 | 6.35 | 0.89 | 0.124 |
| 3/8″ | 0.035 | 9.53 | 0.89 | 0.196 |
| 1/2″ | 0.049 | 12.7 | 1.25 | 0.357 |
| 3/4″ | 0.065 | 19.05 | 1.65 | 0.721 |
| 1″ | 0.065 | 25.4 | 1.65 | 0.981 |
| 1 1/4″ | 0.065 | 38.1 | 1.65 | 1.5 |
| 2″ | 0.065 | 50.8 | 1.65 | 2.03 |
| 2 1/2″ | 0.065 | 63.5 | 1.65 | 2.555 |
| 3″ | 0.065 | 76.2 | 1.65 | 3.08 |
| 4″ | 0.083 | 101.6 | 2.11 | 5.256 |
| 5″ | 0.083 | 127 | 2.11 | 6.564 |
| 6″ | 0.109 | 152.4 | 2.77 | 7.899 |
| 8″ | 0.109 | 203.2 | 2.77 | 10.569 |
Special Sizes Available Upon Request.
